Load Turning Device
Loading range: 1,000 to 100,000 kg
GBCRANES' load-turning devices enable the safe and fast rotation of heavy workpieces. The rotation operation can be stopped at any time to control or correct the workpiece to ensure that the workpiece is not damaged and to effectively avoid accidents.
YOUR CONTACT
Advantage
Mobile use
Manual or electric lateral adjustment
Can be used for series operation
Component protection
Only one person can operate, ensuring a quick return on investment
Provide a variety of options to meet your personalized needs
Application
Bulky goods
Mechanical components
Marine diesel engines
Welded structures
Mold boxes for the foundry industry
Concrete prefabricated parts
Glass bricks or steel ingots
Cast containers
Technical features
Suitable for various types of load flipping.
Compact design, minimizing lifting height loss.
Gear motor equipped with brake.
Steering is controlled by a wireless remote control to ensure a safe distance, no cable interference.
Ensure that the center of gravity is at the center of the component during operation.
Maximum tilt angle: up to 6 degrees relative to the horizontal.
Options
Chain
Available in ring or segmented designs, suitable for different load carrying capacity needs.
Loose roll
Used to rotate long parts and follow the movement of the equipment without the need for electric drive.
Pendant
Operators have the option of using pendant on the load-turning device's beam.
Spring cable drum
Used to establish the power connection between the crane and hoist, available in a variety of lengths.
Technical Data Sheet
Model Load Turning Capacity Qty of Chains/ Slings Design Turning Torque Turning Motor Power Turning Chain Speed Opening and Closing Speed Opening and Closing  Motor Power Structure Type
CTS100T 100t 4 50000N.M 2*7.5kw 2.8m/min 0.98m/min 2*0.55kw Double Girder
CTS80T 80t 4 40000N.M 2*5.5kw 2.5m/min 0.98m/min 2*0.55kw Double Girder
CTS50T 50t 2 25000N.M 2*3.0kw 2.8m/min 0.96m/min 2*0.37kw Single Girder
CTS40T 40t 2 20000N.M 2*3.0kw 2.8m/min 0.96m/min 2*0.37kw Single Girder
CTS20T 20t 2 10000N.M 2*2.2kw 2.5m/min 0.96m/min 2*0.25kw Single Girder
CTS10T 10t 2 5000N.M 2*1.5kw 2.6m/min 0.96m/min 2*0.25kw Single Girder
CTS5T 5t 2 3000N.M 2*1.1kw 2.8m/min 0.96m/min 2*0.25kw Single Girder
CTS3.2T 3.2t 2 1700N.M 2*0.75kw 2.8m/min 0.96m/min 2*0.25kw Single Girder
CTS2T 2t 2 900N.M 2*0.55kw 3.1m/min 0.96m/min 2*0.25kw Single Girder
CTS1T 1t 2 500N.M 2*0.37kw 2.6m/min 0.96m/min 2*0.25kw Single Girder
Interested? Please, contact us.
We respond fast and are ready to help you.

PARTS AND SERVICES

Spare parts
We predict that spare parts business and services will become the future business growth point of GBCRANES, You can see the detailed name and code of the spare part from the random product introduction. According to the equipment batch and code, you can easily purchase the required spare parts from GBCRANES. You can also get the advice of our product manager. According to the detailed maintenance manual, in accordance with the sequence of replacement parts and necessary tools, you can complete the replacement of spare parts independently. Of course, we recommend that you contact us in advance or contact our local service partner according to the maintenance cycle recommendationsin the maintenance manual. GBCRANES will develop suitable service provider partners in your country, city and region to ensure your stable production in later stage. The products of GBCRANES are constantly improving. If the products are upgraded and the parts are changed, the material system will be updated, but we will still reserve the supply of spare parts for our products which you currently use for at least 10 years. You can rest assured to use our products.
Training
The training content includes the use of spreaders and the replacement of spare parts. At present, you can learn how to identify the codes of different parts through the manual and animation. At the project site, there will be professional engineers who will conduct comprehensive training at the end of the project. All training is only for you to firmly master the spreader products.
Return visit
When you use GBCRANES products, you are our vip user. We will have customer service to return visit you regularly to learn about the usage of spreader products and the frequent replacement of spare parts situation by different users, so as to better prepare spare parts for you, and deliver them faster when you need them. Please leave your valuable comments to help us continuously improve our products.
